Specifications |
Model |
CS-H80x-R100-8G82WKFL |
Camera |
Image Sensor |
1/2.7” + 1/2.9” Progressive Scan CMOS |
Shutter Speed |
Self-adaptive shutter |
Lens |
4mm @ F1.0, viewing angle: 46° (Vertical), 87° (Horizontal), 103° (Diagonal) (1080p) 4mm @ F1.6, viewing angle: 46° (Vertical), 87° (Horizontal), 103° (Diagonal) (4K) |
PT Angle |
Pan: 340°, Tilt: 70° |
Minimum Illumination |
0.01 Lux @ (F1.0, AGC ON), 0 Lux with IR (*data is obtained from EZVIZ laboratories) |
Lens Mount |
M12 |
Day / Night Switch |
IR-cut filter with auto switch |
DNR |
3D DNR |
WDR |
Digital WDR |
BLC |
Supports |
Black & White Night |
30m / 98ft |
Video & Audio |
Max Resolution |
3840 × 2160 |
Frame Rate |
Self-Adaptive during network transmission |
Video Compression |
H.265 / H.264 |
H.265 Type |
Main Profile |
Video Bit Rate |
Ultra HD; Quad HD; Full HD;HD. Adaptive bit rate. |
Audio Bit Rate |
Self-Adaptive |
Network |
Wi-Fi Standard |
IEEE802.11b, 802.11g, 802.11n |
Frequency Range |
2.4 GHz ~ 2.4835 GHz |
Channel Bandwidth |
Supports 20MHz |
Security |
64 / 128 - bit WEP, WPA / WPA2, WPA-PSK / WPA2 - PSK |
Transmission Rate |
11b : 11 Mbps, 11g : 54 Mbps, 11n : 150 Mbps |
Wi-Fi Pairing |
AP paring |
Protocol |
EZVIZ Cloud Proprietary Protocol |
Interface Protocol |
EZVIZ Cloud Proprietary Protocol |
Wired Network |
RJ45 × 1 (10M / 100M Adaptive Ethernet Port) |
Functions |
Smart Alarm |
AI-powered human shape detection
AI-powered vehicle shape detection
|
Customized Alert Area |
Supports |
Two-way Talk |
Supports |
Auto Tracking |
Supports |
General Function |
Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark |
Storage |
Local Storage |
Supports microSD Card (Up to 512 GB) |
Cloud Storage |
Supports EZVIZ CloudPlay storage (Subscription required) |
General |
Operating Conditions |
-30ºC ~ 50ºC Humidity 95% or less (non-condensing) |
IP Grade |
IP65 |
Power Supply |
DC 12V/1A |
Power Consumption |
MAX. 12W |
Dimensions |
170 × 112 × 154 mm (6.69 × 4.41 × 6.06 inch) |
Packaging Dimensions |
205 × 176 × 194 mm (8.07 × 6.93 × 7.64 inch) |
Weight |
Product: 630 g (22.22 oz)
Weight with package: 1035 g (36.5 oz)
|
In the box |
In the box |
- H80x Dual 4K Camera |
- Drill Template |
- Waterproof Kit |
- Screw Kit |
- Power Adapter |
- Regulatory Information × 2 |
- Quick Start Guide |
Certifications |
Certifications |
CE / UL / WEEE / RoHS / REAC |
